SPECIFICATION
Model - BULLDOG
Motherboard support - M-ATX、ITX
Front Panel - Tempered Glass
Left Side Panel: - Tempered Glass
Top Cover - With Magnetic dust filter
I/O Port - USB2.0 x1+USB3.0x1+HD Audio
PSU support - ATX / Max length 190mm
Fan Ports
Front: /
M/B: 2*120mm(With)
Top: 3*120mm / 2*140mm
support 360/280/240 AIO
Rear: 1*120 mm (With)
Motherboard support - M-ATX、ITX
Front Panel - Tempered Glass
Left Side Panel: - Tempered Glass
Top Cover - With Magnetic dust filter
I/O Port - USB2.0 x1+USB3.0x1+HD Audio
PSU support - ATX / Max length 190mm
Fan Ports
Front: /
M/B: 2*120mm(With)
Top: 3*120mm / 2*140mm
support 360/280/240 AIO
Rear: 1*120 mm (With)
Bottom: 3*120mm
Drive Bays:
5.25'' ODD x0
3.5'' HDD x2 (share port with SSD)
2.5'' SSD x1 (share port with HDD)
PCI Slots: - x 5
Max.VGA Card: - 420 mm
Max. CPU Cooler: - 165 mm
Cable management space - 96 mm
Size (L*W*H):
Product Size: L442*W280*H369 mm
Carton box: L415*W337*H494 mm
Drive Bays:
5.25'' ODD x0
3.5'' HDD x2 (share port with SSD)
2.5'' SSD x1 (share port with HDD)
PCI Slots: - x 5
Max.VGA Card: - 420 mm
Max. CPU Cooler: - 165 mm
Cable management space - 96 mm
Size (L*W*H):
Product Size: L442*W280*H369 mm
Carton box: L415*W337*H494 mm
